SWAN SONG

Refit 2023 - 2024

All new electronics (see ELECTRONICS below)

Starlink.

Clock and barometer.

Lithium batteries.

Victron battery management.

Tender and outboard.

Main engine timing belt.

Forward cabin mattress and cover.

Running rigging.

Anchor chain and rode.

Hull

Solid fiberglass hull with interior longitudinal and transverse stiffeners.

White gel coat, gold cove stripe, dark blue gelcoat boot stripes.

Epoxy barrier coat applied at the factory when new.

Black bottom paint.

Bronze seacocks and through hull fittings.

Elliptical fin keel with bulb and draft of 7'2".

Elliptical spade rudder.

Deck

Glass fiber deck cored with closed cell foam.

Teak overlay vacuum bagged and glued down.

Larger 47" steering wheel with elk hide cover.

Suunto compass mounted at pedestal.

Transom with recessed platform.

Aluminum anodized toe rail.

Deck access to anchor locker.

Anchor windlass, Lewmar Ocean 3, gypsy only with handheld control (new motor 2011).

Double rollers on stemhead.

Hatch over the forward cabin, head, passageway, galley, navigation station, saloon and aft cabin.

2 x opening ports aft side of coachroof.

2 x opening ports aft end of coachroof coaming.

Floating genoa car system, tow lines lead to the secondary winches including jammers.

Main traveler track over coachroof.

Bow sprit attaches to stem head fitting.

Gate in lifeline port and starboard side.

Halyard jammers Spinlock XX0812.

Outboard bracket on pushpit.

Mug holder on pedestal.

Two coaming stripes.

GRP repeater console above entrance.

Acrylic companionway drop board.

Large cockpit locker under starboard helm cockpit seat.

Large lazarette locker under helm seat.

Fold down stainless-steel boarding ladder at transom.

1 x dorade with 2 cowls forward of mast.

Stainless-steel handrails on coachroof.

3 x pairs of mooring cleats, 2 x forward, 2 x aft and 2 midship.

Socket for flagpole.

Winches

All by Harken:

2 x 56.2 ST, 2 Speed, electric primary.

2 x 48.2 ST, 2 Speed, secondary.

1 x 48.2 ST, 2 Speed, electric mainsheet and halyard.

1 x 48.2 ST, 2 speed halyard and utility.

General Arrangements

Accommodations

Sleeps a total of six. Two in each of the two sleeping cabins and two in the saloon. Two heads. Interior is finished with hand rubbed teak throughout. Teak and holly cabin sole. Minor interior re-varnish as necessary, 2011

Forward Cabin

Double berth with filler and stowage under. Custom mattress with mattress cover and custom sheets (2023). Shelves and cupboards over. Starboard side dresser and hanging locker. Full length mirror. 5'11 headroom.

Forward Head

White gel coated GRP module with teak grating. Enameled wash basin. Pressure hot and cold water. Mirror. Towel and soap holder. Waste container. Lockers with shelves outboard. Headroom 5'11". All head plumbing replaced, 2010.

Main Saloon

Table on the centerline with folding leaves port and starboard and fiddle rails. "U" shaped settee to port and straight settee to starboard. Leather saloon settees and navigation seat. Lockers and shelves outboard of each settee. Custom bookshelf with roll top door on starboard side of saloon for TV. Headroom 6'2".

Galley

Located aft of the saloon and on the port side. "U" shaped. Stainless-steel sink with pressure hot and cold water. Garbage bin below sink. Gimballed Force 10 propane stove with oven and protective stainless-steel bar. Pots and pans locker under stove. Chest of drawers. Technautics Coastal 12 refrigerator and freezer with holding plates, Nautor-made insulated box, front and top loaded refrigeration. Refrigeration powered by 12 volts. Headroom 6'5".

Navigation Station

Located aft of the saloon and on the starboard side. Forward facing. Surrounded with navigation and communication electronics. Headroom 6'5".

Aft Cabin

Located aft of the galley and on the port side. Double berth with filler. Spring mattress with mattress cover and custom sheets (2008). Shelves over full length of berth. Hanging locker forward. Full length mirror. Headroom 6'3".

Aft head

Located on the starboard side and aft of the saloon. Description same as the forward head. Headroom 6'3".

Engine

Volvo Penta MD22L marine diesel, rated 50HP at 3000rpm on flexible mountings with SailDrive.

Timing belt (2023).

Water pump impeller (2023).

Fresh water cooled. D

rip tray integral with engine bed.

Sound proofed engine space.

Engine control panel, behind a smoked plexiglass door, starboard side of cockpit.

Single lever throttle gear control.

Tachometer.

Coolant temperature gauge.

Oil pressure gauge.

Fuel level gauge.

Battery charge warning light.

Low oil pressure, high engine temperature audible alarm.

Engine space ventilation blower.

3 blade Volvo folding prop.

Fuel tank gauge at engine control panel.

Fuel tank dip stick.

Fuel/water separator with alarm.

Plumbing and Ventilation

Deck shower, hot and cold water at transom.

Shower in heads.

2 x Stainless-steel water tanks.

Water tank level gauge at main switchboard.

Hot water, 5.8 gallons, can be heated either from the engine cooling water circulation or from 110 volt AC.

Back up freshwater foot pump at galley.

Freshwater manifold allows for control of tank fills and tank usage.

Saltwater foot pump at galley.

Electric shower sump pumps.

2 x manual bilge pumps.

1 x electric bilge pump.

Par manual toilets saltwater flush.

Stainless-steel holding tank with hand pump for forward and aft heads.

Wiring for heater.

Reverse cycle air conditioning in forward cabin, saloon and aft cabin, Cruisair 16000 BTU, 115V.

Electrical

Lithium Ion batteries with 900A hrs (2023).

Batteries stored under the P saloon settee.

Victron battery management system (2023).

Victron battery charger/inverter (2023).

1 x starting battery, 12V 75 Ah/20h gel.

Additional 115V outlet, at chart table.

Alternator Amptech 12V 125A for service batteries (rebuilt 2023).

Alternator 12 volt, 60 amp, for charging engine and service batteries.

Link 2000R remote control panel with Amp meter and regulator for Freedom Marine 25 2500 watt charger/inverter.

Temperature controller TC+2 for battery charger.

Separate shore power inlet 115 V 25A for air conditioning.

Additional bulkhead lights, 2 pcs, outboard in saloon.

6 x Hella Turbo fan, 2 in forward cabin, 2 on main bulkhead, 1 in galley, and 1 in aft cabin.

Red night lights at floor level.

Battery parallel switch.

Lightening protection with rigging and tanks grounded through keel bolts.

Electronics

KVH Starlink (2024).

New B&G Navigation UPGRADE completed Spring 2023.

Complete upgrade navigation, radar, autopilot, VHF. Installed by Hampton Navigation.

Updated & Serviced by Cay Electronics August 2024.

B&G ZEUS3s at navigation station.

16” B&G Zeus 3s multi-functional chart plotter at navigation station.

1 x Triton2 digital display multi-function 4.1 color sail Instrument at navigation station.

1 x Triton2 speed/depth/wind instrument pack including instrument display, DST810 depth/speed/temperature sensor, WS310 wired wind sensor and a NEMA 2000.

B&G 9” chart-plotter at helm display.

Halo20+ radar bundles includes Zues2s.

Multi-functional chart plotter and Halo20+ radar.

Digital chart: reveal-Nova Scotia to Chesapeake Bay.

2024 Update

NAVIONIC Premium Suite / Cay Electronics August 2024.

B&G ZG100 GPS antenna module pack – rail mounted.

B&G AIS module kit including NAIS-5000, NSPL-500, GPS500 NEMA2000 (to VHF Antenna).

AIS GPS antenna rail mounted.

NEP-2 network expansion port.

Forward underwater scanning module and transducer.

Triton Edge sail processor, compact sailing processor with NEMA2000.

Ethernet and WiFi configuration.

Custom fabricated powder coated NavPod display face plate for 4 x Triton2 display multi-functional 4.1 color sail instruments in cockpit.

AUTOPILOT

B&G Triton2 autopilot controller/display pack.

B&G Autopilot system Includes:

* NAC-3 course computer.

* Precision-9 Compass.

B&G WR10 remote + base station at helm.

B&G WM4 Sirius satellite weather/radio receiver – antenna rail mounted.

NEW ICOM M510 VHF radio at nav station with remote station HM195GB command Mic at the helm.

IRIDIUM GO 9560 satellite terminal with Wi-Fi hotspot – antenna mounted on stern rail. Purchased from Atlantic Radio 10/2022 Miami Boat show – Never used.

Sim Card included.

EPIRB - ACR GlobalFix V4 Cat 1 Class 2 with case for rail mount – never used/or setup.

Weems & Plath new 2023 chiming clock & barometer.

Rigging

Three-spreader aluminum mast, tall option, stepped on the keel

Antal sail track system for mainsail

Adjustable mast step for rig tuning

Aluminum boom

Carbon fiber spinnaker pole

Stainless-steel rod standing rigging

Full out-of-boat standing rigging assessment and replacement as necessary, 2011

Inner forestay with mast and deck fittings, shroud roller and halyard included

Shroud rollers on main shrouds

Separate fore stay with Tuff Luff foil fitted for racing

Deck flood light mounted on mast

Navtec hydraulics for backstay tensioner and boom vang

Harken headsail roller furling

Running rigging, (2023)

Sails

Mainsail, Quantum Fusion 8000 (Carbon and Vectran) with Dutchman system, 2009

130% genoa, Quantum Fusion 8000 (Carbon and Vectran) 2010

Mainsail for racing, North 3DL Marathon, 2003

Light/medium #1 genoa, with Tuff Luff, North 2006

#3 genoa with Tuff Luff, North 2002

Medium 3DL Marathon genoa, North, 2004

Cruising genoa, North, 1996

Code 1 Asymmetrical .65 ounce spinnaker, North,

Code 2 Symmetrical .75 ounce spinnaker, North, 2006

Code 2 Symmetrical .50 ounce spinnaker, North, 2006

Code 4 Symmetrical 1.5 ounce spinnaker, North, 2006

Storm jib, North, 2006

Additional Equipment

Achilles LSR-290E, 6'9" inflatable dinghy (2024).

Mercury 5hp, outboard engine (2024).

Stern rail mounted outboard engine davit.

3x Pull-out mosquito screens/blinds for saloon, forward cabin and aft cabin hatches

Cockpit table

Cockpit upholstery, white with dark blue piping

Crew covers for saloon upholstery and saloon table (2007)

Heavy weather webbing safety lines 19"

Samsung TV.  TV can be used as a monitor for the computer

Alpine CD 9851 Radio/CD-player in saloon with Sirius adapter and Ipod adapter, with two loudspeakers

MB Quartz 6.5" 2 way loudspeakers in cockpit

Lee cloth for saloon settee

Elk hide on mast in saloon

Wine storage in forward cabin seat

Corian covers for sink

Extractor fan in each head

1 x 45lb CQR anchor.

200 feet of chain and 150 feet of 8 plait rode (2024).

4 x medium fenders with fleece liners

2 x large fenders with fleece liners

1 x boat hook

Fairclough full winter cover, mast in, 2009

Grey Sunbrella dodger, binnacle and wheel covers 2011

Grey Sunbrella mainsail cover 2012

Disclaimer

The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
