WAFI

Hull

Blue gelcoat solid fiberglass hull using isopolyester laminate and vinylester skin coat.

Uncolored gel coat below waterline.

Epoxy barrier coat below waterline.

Multiaxial or unidirectional fibers in selected areas.

Structural bulkheads are of marine plywood, laminated to hull and deck with foam strips between.

Flanges are unidirectional lay-ups over hollow cores glassed inside the hull for extra hull stiffness.

Engine beds are of GRP.

Single white sheer stripe.

Double white waterline stripe.

Dagger board version with 4’ draft board up.

The fiberglass dagger board operates with hydraulics.

There is an extra approximately 4,400lbs ballast in this dagger board version of the Swan 461 to maintain similar righting moment to the standard keel Swan 461.

Twin spade rudder blades, each shorter than the keel with board up.

Rudder stocks are high tensile steel.

Drop down Max Power bow thruster.

Drop down swim platform operated manually with teak overlay at transom.

Swim ladder from swim platform.

Bronze seacocks below the waterline.

Deck

Multiaxial glass fiber reinforced isopolyester laminate decks, cored with low density closed cell foam.

High density core used under deck fittings.

Teak overlay.

White gel coat where there is no teak overlay.

Blue deck coaming stripe.

Stainless-steel chain plates for forestay, shrouds and backstay.

Stainless-steel stem head fitting with Delrin anchor roller.

Stainless-steel bow and stern rails.

1 x 19 stainless-steel wire double lifelines.

Lifeline gate port and starboard.

Lewmar electric windlass in anchor locker.

3 x pair aluminum mooring cleats, 1 x pair forward, 1 x pair midship, 1 x pair aft.

2 x pair fairleads for mooring lines, 1 x pair forward, 1 x pair aft.

2 x steering pedestals each with elk hide covered stainless-steel wheels with locking nuts.

Emergency tiller position in cabin sole aft of wheels.

Carbon radar antenna pole on starboard aft transom.

3 x opening deck hatches.

Anchor locker forward with deck access.

Cockpit locker starboard side under cockpit seat for life raft storage.

Gas bottle locker under helm seat starboard side.

Locker under helm seat port side.

Lazarette locker access from hatch in cockpit floor aft.

Stand up blocks at mast partners to help direct running rigging.

Running rigging leads under deck from mast partners aft to clutches forward of winches.

Mainsheet leads under deck either side to their own winches aft.

1 x pair Harken aluminum jib tracks with 2 cars on each track and towing lines.

Gennaker sheet blocks aft.

Gennaker tack line block on stem with line led aft below deck.

Fixed deck attachment in cockpit for mainsheet.

Folding padeyes in cockpit for harness attachment.

Guttering surrounds the companionway in a horseshoe shape to house a folded dodger.

4 fixed ports, 2 each side in coachroof coaming.

4 opening ports, 2 each side in coachroof coaming.

2 opening ports from port aft cabin to cockpit.

Tinted acrylic sliding companionway hatch with sliding drop board.

Winches

All Lewmar and all electric.

2 x #54, ST, 2 speed primaries.

2 x #50, ST, 2 speed mainsheet/secondaries.

2 x #48, ST 2 speed halyard/utility.

General Arrangement

Accommodations

Sleeps 7 in 3 separate sleeping cabins, plus 2 more on the main saloon for a total of 8. 2 heads. Varnished, hand rubbed, Burmese teak interior furniture. Oak and teak cabin sole. Vinyl overhead panels.

Forward Head

Located in the bow and access from the master cabin. Full width. White gel coat fiberglass unit to half height. Teak above. Manual head to starboard. Sink to port. Teak shower grating in floor. Electric sump pump for the shower tray. Telephone type shower. Curtain to isolate the shower. Mirrors and lockers outboard, port and starboard. White Corian counter tops. Stainless-steel holding tank with deck or overboard discharge.

Master Cabin

Located in the bow immediately aft of the forward head. Double offset Pullman type bunk to port. Settee to starboard that can be a bunk. Lockers and shelving outboard port and starboard. Hanging locker port side forward. Access door to saloon aft on starboard side.

Main Saloon

Located aft of the master cabin. Straight settee to starboard. “L” settee to port surrounding a dining table that slides fore and aft allowing more access to seating. Dagger board trunking midship forward. Lockers and shelves outboard to port. Lockers to starboard with electronics aft behind settee.

Galley

Located starboard side and aft of the saloon. “L” shaped. Double steel sinks forward. Overhead lockers over sinks. Lockers and drawers under sinks. Microwave oven forward and outboard. Top load freezer outboard and forward.  3 x burner propane stove with oven outboard. Side load fridge outboard and aft. Locker space outboard and full length of galley. White Corian counter tops. Clear Plexiglass splash panel forward. Refrigeration system is battery driven.

Aft Head

Located on the port side aft of the saloon and opposite the galley. White gel coat fiberglass unit to half height. Teak furniture above. Manual head aft. Sink outboard. Teak shower grate. Electric sump pump for the shower tray. Mirror and lockers outboard. White Corian counter tops. Stainless-steel holding tank with deck or overboard discharge.

Aft port cabin

Located immediately aft of the aft head and on the port side. Double bed. Lockers and shelving outboard. Hanging locker outboard and forward. Drawers under bunk.

Aft starboard cabin

Located immediately aft of the galley on the starboard side. “V” double berth. Lockers and shelving outboard. Hanging locker forward and outboard.

Engine

Volvo Penta D2 55, 53hp at 3,000rpm, diesel engine.

1,230hours on engine as of August 2026.

SailDrive transmission.

3 blade Flexofold folding propeller.

3 x stainless-steel diesel tanks each with inspection port and fuel gauge totaling 75 gallons.

Access to the engine space is from side panels and from under the companionway steps.

Engine space has air inlet with water trap, and exhausts via a blower.

Single lever engine control and engine instruments next to starboard helm station.

Plumbing and ventilation

3 x stainless-steel freshwater tanks totaling 105 gallons.

Vents for freshwater tanks terminate at galley sinks.

2 x electric bilge pumps.

3 x manual bilge pumps.

8 gallon water heater. Water heated via heat exchanger off the engine or AC.

2 x stainless-steel black water tanks totaling 22 gallons.

Deck wash.

2 x Dorade vents on deck.

Diesel forced air heating.

Webasto Blue Cool Premium 30,000btu, Air conditioning with temperature control in each cabin.

Electrical

230 volt AC system.

24 volt DC system.

For lightening protection, the head stay, backstay, shroud chainplates and mast step are grounded to the keel bolts.

Shore power deck connection.

AC/DC electrical breaker panel is opposite the galley and next to the companionway steps on starboard side.

AC/DC panel also has volt and amp meters, fuel and water tank level gauges.

24volt/230volt inverter.

2 x alternators on front of engine, 1 x 110amp for house batteries, 1 x 60amp for engine start battery.

1 x engine start battery.

2 x bow thruster batteries.

2 x lithium ion house batteries.

Dedicated battery for electronics.

Battery boxes ventilated to outside.

12volt outlet at nav station and cockpit.

Reading lights at each bunk.

Recessed halogen overhead dome lighting.

Red night lights in galley and nav station.

Separate entrance light at companionway.

Compass light.

Anchor light.

Steaming light.

Deck lights.

Removable solar panels.

Mastervolt Solar Charger, MASTER SCM-25.

Electronics

Raymarine chart plotter mounted into forward starboard cockpit bulkhead.

Raymarine analogue ST60 read out at starboard pedestal.

Raymarine ST6002 autopilot display at starboard pedestal.

Raymarine ST60 analogue wind display at port pedestal.

Raymarine ST60 digital display at port pedestal.

2 x Raymarine analogue wind direction and wind speed read outs over companionway.

2 x Raymarine digital multi read outs over companionway.

2 x Suunto compasses, 1 at each helm station.

Raymarine depth read out st starboard helm position.

ICS Nav6 Navtex screen at nav station.

Raymarine Graphic display at nav station.

Ray240E at nav station.

VHF hand sets at each helm.

Rigging

Offshore Spars, white painted, aluminum mast.

Double aft swept spreaders.

Navtec stainless-steel rod standing rigging.

Removable Dyneema inner forestay and checkstays.

Offshore Spars white painted aluminum boom.

Harken headsail roller furler.

Navtec hydraulic backstay, boom vang and outhaul.

Sails

All North.

Mainsail, 3Di Endurance 760, with 2 reefs and full battens (2023).

Mainsail, Spectra, with 2 reefs and full battens (2007).

110% jib, 3DL Marathon, (2014).

109% jib, light, 3DL (2009).

100% jib, heavy, 3DL (2009).

109% jib, Spectra, furling, (2007).

80% jib, Spectra, furling (2007).

Code Zero, 60%, Dyneema, with Facnor furler (2009).

A2, 1.5oz, with snuffer (2009).

A3, 1.5oz, with snuffer (2009).

A5, 2.5oz, (2007).

Trysail, Dacron (2007).

Staysail, Dacron, (2007).

Additional Equipment

Emergency tiller.

Delta 44lb anchor.

10m of 8mm anchor chain.

50m anchor rode.

4 x mooring lines.

4 x air fenders.

Boat hook

4 x 10” winch handles.

Bosun’s chair.

Flagpole.

Engine tool kit.

Sounding rods for water and fuel tanks.

Suction cup to lift floorboards.

Safety Equipment

Fixed fire extinguisher in engine space with release handle at companionway.

2 x portable fire extinguishers.

Fire blanket for galley.

Ondeck jacklines to attach harnesses.

Safety belts for navigator and cook.

6 person life raft.

Life ring.

MOD sling.

6 x PFD, Crewsaver, with harness.

6x harnesses.

Canvas

Sun awning from mast to backstay.

Main boom cover.

Wheel covers.

Dodger.

Full interior cushion covers, navy blue.
